How to Add HAProxy with SSL Termination and Load Balancing for Ceph RGW and Dashboard

In our previous post, we installed Ceph Squid v19 with RGW S3 and the Ceph Dashboard on three Ubuntu 24.04 bare-metal nodes. RGW runs on port 8081, and the Dashboard runs on port 8080 with SSL disabled.

In this follow-up, we’ll add HAProxy in front of both services, with:

SSL termination using Let’s Encrypt (DNS challenge)
Load balancing across RGW nodes
Dashboard access over HTTPS (on port 8443)
S3 API exposed via HTTPS (on port 443)
Automatic certificate renewal

Cluster Topology

Hostname	IP Address	Role
ceph.maksonlee.com	192.168.0.81	HAProxy + SSL termination
ceph-1.maksonlee.com	192.168.0.82	MON, MGR, RGW (8081), Dashboard (8080)
ceph-2.maksonlee.com	192.168.0.83	RGW (8081)
ceph-3.maksonlee.com	192.168.0.84	RGW (8081)

Install HAProxy 3.2 from PPA

sudo add-apt-repository ppa:vbernat/haproxy-3.2 -y
sudo apt update
sudo apt install -y haproxy=3.2.*
sudo systemctl enable --now haproxy

Install Certbot with DNS Plugin

sudo apt install -y certbot python3-certbot-dns-cloudflare
mkdir -p ~/.secrets/certbot
vi ~/.secrets/certbot/cloudflare.ini

dns_cloudflare_api_token = YOUR_CLOUDFLARE_API_TOKEN

chmod 600 ~/.secrets/certbot/cloudflare.ini

Request SSL Certificate

sudo certbot certonly \
  --dns-cloudflare \
  --dns-cloudflare-credentials ~/.secrets/certbot/cloudflare.ini \
  -d ceph.maksonlee.com

Bundle Certificate for HAProxy

sudo mkdir -p /etc/haproxy/certs/
sudo bash -c "cat /etc/letsencrypt/live/ceph.maksonlee.com/fullchain.pem \
  /etc/letsencrypt/live/ceph.maksonlee.com/privkey.pem \
  > /etc/haproxy/certs/ceph.maksonlee.com.pem"
sudo chmod 600 /etc/haproxy/certs/ceph.maksonlee.com.pem

Configure HAProxy (443 → RGW, 8443 → Dashboard)

Edit /etc/haproxy/haproxy.cfg:

# S3 over 443
frontend fe_s3_https
  bind *:443 ssl crt /etc/haproxy/certs/ceph.maksonlee.com.pem
  mode http
  default_backend be_rgw_s3

# Dashboard over 8443
frontend fe_dashboard_https
  bind *:8443 ssl crt /etc/haproxy/certs/ceph.maksonlee.com.pem
  mode http
  default_backend be_dashboard

backend be_rgw_s3
  mode http
  balance roundrobin
  server rgw1 192.168.0.82:8081 check
  server rgw2 192.168.0.83:8081 check
  server rgw3 192.168.0.84:8081 check

backend be_dashboard
  mode http
  server ceph1 192.168.0.82:8080 check

Reload HAProxy:

sudo systemctl restart haproxy

Automate Certificate Renewal

Create deploy hook to reload HAProxy on renewal:

sudo tee /etc/letsencrypt/renewal-hooks/deploy/reload-haproxy.sh > /dev/null <<EOF
#!/bin/bash
cat /etc/letsencrypt/live/ceph.maksonlee.com/fullchain.pem \
    /etc/letsencrypt/live/ceph.maksonlee.com/privkey.pem \
    > /etc/haproxy/certs/ceph.maksonlee.com.pem
systemctl reload haproxy
EOF

sudo chmod +x /etc/letsencrypt/renewal-hooks/deploy/reload-haproxy.sh

Final Test

Access Ceph Dashboard

https://ceph.maksonlee.com:8443

Access Ceph S3 API (via AWS CLI)

s3cmd --configure
s3cmd --dump-config | grep host_

host_base = ceph.maksonlee.com:443
host_bucket = ceph.maksonlee.com

s3cmd ls

2025-07-27 08:40  s3://testbucket

With HAProxy handling SSL, routing, and load balancing, your Ceph RGW and Dashboard setup is now scalable and production-ready, with secure HTTPS access and seamless certificate automation.
